Selection of grating panels for vehicle traffic

  • Q - total vehicle weight, with allowed payload [T]
  • P = a / b
  • a - value of the maximum pressure on the most loaded wheel
  • b - "a" increased by the dynamic factor (vibration, braking) [T]
  • A - area subjected to the "P" pressure [m x m]
  • RL - movement along the bearing-bars
  • RB - direction of movement perpendicular to the bearing-bars
Welded gratings, bearing-bars spacing 34,3 mm
Structural support spacing [mm] cars-gratings
Cars		 Fork-lift_trucks_gratings
Fork-lift trucks		 Trucks-gratings
Trucks		 Trucks-gratings
Trucks with trailers
Q=2,5 T Q=2,5 T Q=3,5 T Q=7,0 T Q=13 T Q=6,0 T Q=9,0 T Q=12 T Q=30 T Q=60 T
P=0,48/0,624 P=1/1,3 P=1,5/1,95 P=3,25/4,225 P=6/7,8 P=2/2,6 P=3/3,9 P=4/5,2 P=5/6,5 P=10/13
Fv 30,7 21,3 15,7 12,0 9,5 7,7 6,3 5,3 4,5 3,9 3,4 3,0 2,7 2,4
A=0,2x0,15 A=0,2x0,2 A=0,2x0,2 A=0,2x0,2 A=0,2x0,2 A=0,2x0,2 A=0,2x0,26 A=0,2x0,3 A=0,2x0,4 A=0,2x0,6
RL RB RL=RB RL=RB RL=RB RL=RB RL=RB RL RB RL RB RL RB RL RB
300 40x4 40x4 40x4 40x4 50x5 70x5 40x5 50x4 50x4 50x4 50x5 50x4 50x4 60x4 60x4
400 40x4 40x4 40x4 40x5 60x5 - 50x5 50x5 60x4 60x5 60x5 60x5 60x5 70x5 70x4
500 40x4 40x4 40x5 50x5 70x5 - 60x4 60x5 70x4 70x5 70x5 70x4 - - -
600 40x4 40x4 50x4 60x4 - - 60x5 70x5 70x5 - - 70x5 - - -
700 40x4 40x4 50x5 60x5 - - 70x5 - - - - - - - -
800 40x5 40x4 50x5 60x5 - - 70x5 - - - - - - - -
900 40x5 40x5 60x4 70x5 - - - - - - - - - - -
1000 50x4 40x5 60x5 70x5 - - - - - - - - - - -
1100 50x4 50x4 60x5 - - - - - - - - - - - -
1200 50x5 50x4 70x4 - - - - - - - - - - - -
1300 60x4 50x5 70x5 - - - - - - - - - - - -
1400 60x4 60x4 70x5 - - - - - - - - - - - -
1500 60x5 60x4 70x5 - - - - - - - - - - - -
